Fully compatible with the Jetson Orin Nano Developer Kit reference carrier. Prototype on the Dev Kit, ship on NEXUS-N1, with no software port in between.

Compare modules Datasheets

157

TOPS peak, Orin NX 16GB

1024

Ampere CUDA cores

102

GB/s LPDDR5 bandwidth

7–40

Watt configurable power

Runs unchanged

Software, device trees and BSPs written for the Jetson Orin Nano Developer Kit boot as they are.

One carrier, four modules

Every Jetson Orin Nano and Orin NX module fits the same board. Scale without a redesign.

Full NVIDIA stack

JetPack 6 and JetPack 7 with Jetson Linux, CUDA, TensorRT and DeepStream.

Module options

Pick your performance

AI performance figures are sparse INT8.

Nano series

Orin Nano 4GB

34TOPS

512 CUDA cores, 16 tensor cores
6-core Arm Cortex-A78AE
4GB 64-bit LPDDR5, 51 GB/s
7 W to 25 W

Nano series

Orin Nano 8GB

67TOPS

1024 CUDA cores, 32 tensor cores
6-core Arm Cortex-A78AE
8GB 128-bit LPDDR5, 102 GB/s
7 W to 25 W

NX series

Orin NX 8GB

117TOPS

1024 CUDA cores, 32 tensor cores
6-core Arm Cortex-A78AE
1x NVDLA v2 accelerator
8GB 128-bit LPDDR5, 102 GB/s
10 W to 40 W

NX series

Flagship

Orin NX 16GB

157TOPS

1024 CUDA cores, 32 tensor cores
8-core Arm Cortex-A78AE
2x NVDLA v2 accelerator
16GB 128-bit LPDDR5, 102 GB/s
10 W to 40 W

Carrier board

Every interface, where you expect it

103 x 90.5 x 34.77 mm with module and thermal solution

NEXUS N1 carrier board top view with numbered interface callouts

01USB Type-C (UFP)
02Gigabit Ethernet (RJ45)
034x USB 3.2 Gen2 Type-A
04DisplayPort 1.2 (+MST)
05DC power jack
0640-pin expansion header
07SO-DIMM module connector
08CAM1 MIPI CSI-2
09CAM2 MIPI CSI-2
104-pin fan header
1112-pin button header
124-pin CAN FD header

MIPI CSI-2 camera

22-pin, 2 and 4-lane

M.2 Key M (NVMe)

x4 and x2 PCIe Gen3

M.2 Key E slot

Wi-Fi expansion

USB 3.2 Gen2 Type-A

Plus 1x USB Type-C

CAN FD bus

Dedicated 4-pin header

Pin expansion header

UART, SPI, I2S, I2C, GPIO

Specifications

Technical data

Parameter	Orin Nano 4GB	Orin Nano 8GB	Orin NX 8GB	Orin NX 16GB
AI performance	34 TOPS	67 TOPS	117 TOPS	157 TOPS
GPU	Ampere, 512 CUDA / 16 tensor	Ampere, 1024 CUDA / 32 tensor	Ampere, 1024 CUDA / 32 tensor	Ampere, 1024 CUDA / 32 tensor
CPU	6-core A78AE, 1.5MB L2 + 4MB L3	6-core A78AE, 1.5MB L2 + 4MB L3	6-core A78AE, 1.5MB L2 + 4MB L3	8-core A78AE, 2MB L2 + 4MB L3
DL accelerator	None	None	1x NVDLA v2	2x NVDLA v2
Memory	4GB 64-bit LPDDR5, 51 GB/s	8GB 128-bit LPDDR5, 102 GB/s	8GB 128-bit LPDDR5, 102 GB/s	16GB 128-bit LPDDR5, 102 GB/s
Storage	SD card, external NVMe	SD card, external NVMe	External NVMe	External NVMe
Video encode	1080p30 on 1 to 2 CPU cores	1080p30 on 1 to 2 CPU cores	1x 4K60, 3x 4K30, 6x 1080p60	1x 4K60, 3x 4K30, 6x 1080p60
Video decode	1x 4K60, 2x 4K30, 5x 1080p60	1x 4K60, 2x 4K30, 5x 1080p60	1x 8K30, 2x 4K60, 4x 4K30	1x 8K30, 2x 4K60, 4x 4K30
Power	7 W to 25 W	7 W to 25 W	10 W to 40 W	10 W to 40 W

AI performance figures are sparse INT8. Video codec figures are H.265.

Carrier board

Camera: 2x MIPI CSI-2 22-pin (2-lane and 4-lane)
PCIe: M.2 Key M x4 Gen3, M.2 Key M x2 Gen3, M.2 Key E
USB: 4x USB 3.2 Gen2 Type-A, 1x USB Type-C (UFP)
Networking: 1x Gigabit Ethernet (RJ45)
CAN: 1x CAN FD on a dedicated 4-pin header
Display: 1x DisplayPort 1.2 (+MST)
Other I/O: 40-pin header, 12-pin button header, 4-pin fan header, DC jack
Mechanical: 103 x 90.5 x 34.77 mm, complete with module and cooler

Software

The NVIDIA stack you already use

JetPack 7.2

Jetson Linux 39.2, Ubuntu 24.04

Latest

JetPack 6.2

Ubuntu 22.04

Jetson Linux CUDA TensorRT DeepStream

Applications

Defense · Drones · Robotics

Defense

Drones

Robotics

Machine vision

Datasheets

PDF

NEXUS-N1 for Jetson Orin Nano

NX-N1-DS · Rev 1.8

PDF

NEXUS-N1 for Jetson Orin NX

NX-N1-NX-DS · Rev 1.8
